| Electrical | |
| Operating Frequency | 902-928 MHz |
| Band width | 26 MHz |
| Gain | 15 dBi |
| F/B Ratio | ≥30 dB |
| Polarization | Vertical or Horizontal |
| Horizontal Beam width | 10° |
| Vertical Beam width | 14° |
| V.S.W.R | ≤1.5 |
| Lightning Protection | DC-Grounded |
| Radiation | Direction |
| Maximum Input Power | 100W |
| Impedance | 50Ώ |
| Connector | N Female |
| Cable Type | LMR400 |
| Cable Length | 30 CM |
| Mount way | Pole |
| Diameter of Installation Pole | Ø30~Ø50mm |
| Mechanical | |
| Dimensions | 600x900mm |
| Weight | 3.5KG |
| Rated wind velocity(m/s) | 241Km/h |
| Operating Temperature | -40° to +80°C |
| RoHS Compliant | Yes |
