SST Sensing and Sparkfun collaborate on Arduino-based liquid level sensing hardware
In order to address the constantly expanding maker market, SST Sensing Ltd. has partnered with Sparkfun. Together they have developed a reportedly simple to implement solution for single point liquid detection using infra-red technology.
This solution is said to be reliable and accurate, comprising an Optomax Digital liquid level switch which is connected to an Arduino board via the TTL output and powered by its 5V source.
LEDs on the Arduino can be easily programmed to indicate if the sensor is/isn’t immersed by the liquid (and thus determine if liquid level is too high/low). Using this hardware, hobbyists are provided with plenty of scope to experiment, while professional engineers have the opportunity to evaluate their prototype before moving on to a full scale design.
The Optomax devices have compact dimensions that allow them to be deployed within environments where there is only limited available space. As relatively long cabling can be supported, the sensor can be placed in close proximity to a liquid without any risk of the accompanying electronics on the Arduino being damaged.
Furthermore, as this solution is of an optical rather than a mechanical nature, issues such as the build-up of deposits, jamming, or wear and tear are avoided. A long term operational life span is thereby assured.
The liquid level switch can be supplied by SST in a robust housing with either a Polysulfone or Trogamid® construction (depending on the particular application requirements). The complete solution has an operational temperature range that covers -25°C to +80°C. To see a video showing this solution in action click here.
