AggreGate SCADA/HMI has advanced data acquisition and processing capabilities inherited from AggreGate Device Management Platform, such as real-time charting, comprehensive alerting/reporting and batch operations. It is bundled with a rich set of device drivers for accessing and controlling different PLCs, sensors and other industrial devices. Most industry-standard protocols, such as OLE for Process Control (OPC), Modbus (TCP, UDP, Serial RTU/ASCII/BIN), BACnet IP, and SNMP, are supported directly.

Integrated HMI Builder application simplifies creation of Human-Machine Interfaces for visualizing processes. Available user interface components include standard form elements (e.g. text fields and buttons), tables, raster and vector images, highly customizable gauges, charts, splittable/tabbed/multi-layer panels, and many more. HMI applications created in GUI Builder can be launched separately, e.g. in touch panels.

Advanced SCADA System

  • Support for a wide range of industrial control protocols
  • Distributed architecture, free unlimited client licenses
  • Failover clustering for high availability
  • Advanced event processing and logging
  • Visual HMI editor with intuitive data bindings
  • Remote editing of HMIs and report templates
  • Multi-type trending, support for dynamic charts
  • Fully functional free version (for 100 tags)



Technical Specification

  • HTML5-based web interface
  • License Type: Shareware



Based on M2M Platform

AggreGate SCADA/HMI is built atop of mature and powerful AggreGate Device Management Platform. The SCADA inherits all technological benefits of the underlying framework, including open-source APIs, failover clustering support, distributed architecture, and more.

Innovative Technology

The patented technology of AggreGate IoT Platform introduces many innovations in the industrial automation domain. The system core has integrated support for a home-grown device data normalization method, two-way device synchronization which substitutes simple polling, device data caching, and other advanced operations.

Linux SCADA

AggreGate is a cross-platform SCADA system which can be installed on Linux servers and even under Mac OS X. The system preserves 100% of its functionality when working under non-Windows operating systems. It can also communicate with Windows-based OPC servers via network using DCOM technology.

Wide Protocol Support

AggreGate SCADA/HMI supports most widespread industrial control protocols out-of-the-box, including Modbus, OPC, BACnet, SNMP, and many more. Drivers for PLCs which use other protocols can be easily designed using an open-source Driver Development Kit (DDK).

Alarming and Event Processing

Advanced expression-based alerting with hysteresis (deadband) support. Event correlation and value flapping detection. Alert acknowledgment and escalationrules. E-mail, SMS, popup, sound, and other notifications. Automatic and interactive corrective actions. Flexible event processing chains and long-term storage.

Visual HMI Builder

The integrated HMI Builder supports combining grid and absolute layouts inside different containers within one widget, allowing to build very complex equipment control screens. More than 100 component types are supported, including container components, such as Tabbed Pane or Split Pane.

Charting and Trending

Dynamic chart library supports more than 25 chart types, exposing thousands of configurable parameters for setting up axes, series renderers, legends, titles, gridlines, crosshairs, etc. Trend of different types can be added, including linear, exponential, moving average or percentile.

Statistical Process Control

AggreGate SCADA can store long-term time series data in a round-robin database (RRD) providing extremely compact storage and fast access to historical values. Never seen in other SCADA systems, this feature can help with deep data analysis, such as triggering an alert when a daily channel average significantly exceeds its yearly average.

Live Project Editing

Unlike traditional SCADAs, AggreGate has no difference between development and runtime environments, and no "projects". All development and administrative operations are performed remotely on a production server via secure network connections. Simulation devices, change history tracking, database backups and optional failover servers keep operations safe.

Scripting and Querying

Despite the system is tailored for visual operations, it has strong support for both server-side and HMI-side scripting. The scripts are written in pure Java language exposing all system libraries to a developer. Plus, AggreGate SCADA has two domain-specific languages: query language for data mining and expression language for building alert triggers, event filters, etc.

Task Scheduler

All system actions supporting unattended mode may be executed according to simple or advanced schedule. Simple schedule ensures that the job is executed every N seconds, while advanced schedule allows fine-grained planning, such as "Every 3-rd Friday of May, at 23:30, during years 2011-2015".

Reporting

Any type of license allows creating unlimited number of reports. Report source data may be extracted by expression or by query, but Design Builder tool can create report template from any tabular data in just two clicks. Moreover, the templates can be fine-tuned or created from scratch in the embedded Report Editor.

SQL Support

AggreGate SCADA/HMI stores both configuration and trend values in the SQL database to ensure uniform data access. Most enterprise-grade databases are supported, including MySQL, MS SQL Server, Oracle, PostgreSQL, and others. Trend data storage is fully configurable in terms of sampling periods and storage duration.

SCADA Symbol Library

The installation bundle includes a large library of dynamic automation symbols in Scalable Vector Graphics (SVG) format. The library is divided into multiple categories, like tanks, valves or pipes. All symbols support on-the-fly manipulations, such as changing colors/strokes, zoom and rotation, starting/stopping animations, and manipulating individual elements (e.g. tank levels).

Open-source SDK

AggreGate Server provides open-source APIs for Java and .NET. These APIs allow full remote control of the server and access to all server/device data from any third-party application. It's also possible to create new device drivers and data processing/presentation plugins. In addition, AggreGate Server can be controlled via Web Services.

Flexible Security Model

AggreGate Platform establishes serious security infrastructure for AggreGate SCADA/HMI by providing flexible role-based access control. In addition, all communications between server, operator workstations, HMIs and third-party systems are performed via SSL-secured connections.
